CENTRAL-48-HP-C-230B00-O 48K MRCOOL® Hyper Heat Central Ducted Condenser

$2,927.00

48K MRCOOL® Hyper Heat Central Ducted Condenser

SKU: CENTRAL-48-HP-C-230B00-O Category: Tag: Brand:

Description

The 48K MRCOOL® Hyper Heat Central Ducted Condenser is crafted to provide outstanding performance in even the most extreme climates, from icy winters to scorching summers. This Hyper Heat system utilizes DC Inverter technology and variable speed functionality to deliver consistent, high-quality operation. With a SEER2 rating of up to 16.5 and an HSPF2-4 rating of up to 9.5, it offers powerful heating and cooling while maximizing energy efficiency. A MRCOOL® Smart thermostat is included, giving you complete control over your indoor environment with ease. The 48K MRCOOL® Hyper Heat Central Ducted Condenser is compatible with the 48K MRCOOL® VersaPro® Central Ducted Air Handler. The air handler is built for flexibility, supports various installation options, and is compatible with an optional heat kit for added capability. The system features R-454B refrigerant, a sustainable choice that minimizes its impact on the environment. Durability is a hallmark of the outdoor heat pump, constructed with a painted galvanized steel exterior for long-term resilience. The air handler is thoughtfully designed with a compact form, slide-out blower, and self-diagnostic panel to streamline maintenance and troubleshooting. Enjoy peace of mind with the system’s 10-year warranty, covering the compressor, parts, and labor. The labor warranty activates automatically upon installation, so no registration is required. Enhance your home’s comfort with the efficient and reliable 48K MRCOOL® Hyper Heat Central Ducted Condenser today!

Additional information

Unit Type

Split System Heat Pump

Equipment Type

Condenser

Seer2

16.5

Eer2

10.5

Cfm

3037.1

Tonnage

4

Cooling capacity BTU

48000

Heating Capacity Btu

50000

Voltage V

208-230

Phase

1

Cycle Hz

60

Max Fuse Breaker A

40

Min Circuit Ampacity A

38

Color

gray

Refrigerant Type

R454B

Refrigerant Volume Oz

134.04

Decibel Rating Dba

65

Liquid Line Size

3/8

Suction Line Size

3/4

Wifi Compatibility

Yes

Energy Star Certified

Yes

Ahri Certified

Yes

Brochure

https://www.mrcool.com/wp-content/dox_repo/mc-cd-hh-gen-2-br-en-01.pdf

Install Manual

https://www.mrcool.com/wp-content/dox_repo/mc-vp-HH-CDU-im-um-en-01.pdf

Specs

https://doxrepo.mrcool.com/mc-cd-hh-gen-2-perf-specs-en-01.pdf

Ahri Certs

https://www.mrcool.com/wp-content/dox_repo/AHRI/mc-CENTRAL-48-HP-C-230B00-O-certs.pdf

Energy Guide Certs

https://www.mrcool.com/wp-content/dox_repo/EnergyGuide/mc-eg-CENTRAL-48-HP-C-230B00-O-certs.pdf
